bis 55 Amps

Steckverbinder bis 55 Amps

Up to
55 Amps		Primary PositionsSignal PositionsConnector
Attributes
Amps (UL) (up to)Amps (CSA) (up to)Wire Sizes AWG Wire Sizes mm²Quantity of Positions (up to)First Mate GroundWirePCBBus BarQuantity
of
Positions
(up to)		Touch SafeSealedBlind Mate
4 Position Solar
SPEC Pak® 		202624 to 100.25 to 4.04●●  16●●
3 Pole Mini PL
SPEC Pak® 		221624 to 120.25 to 2.53●●  *●●
5 Pole Mini PL
SPEC Pak® 		231624 to 120.25 to 2.53●●  *●●
MARC Connector292920 to 100.25 to 6.08●●     ●
PowerMod® 303024 to 120.25 to 2.53 to 30●●● *  ●
SAF-D-GRID,
AC 300 Volt		303018 to 100.75 to 4.03●●   ●
SAF-D-GRID,
DC 400 Volt 		303018 to 100.75 to 4.0 3 ●●●  ●
PP10 & PP30,
Pin & Socket 		303016 to 101.3 to 5.31●●●
Power Drawer®
35 Amp 		353516,128.4, 2.58●●● 21  ●
4 Position
SPEC Pak® 		402624 to 100.25 to 4.04●●  16●●
6 Position
SPEC Pak® 		452924 to 100.25 to 4.06●●   ●●
Powerpole®
Blindmate		454020 to 100.25 to 4.02 to 8●●●  ● ●
Powerpole® Pak454020 to 100.25 to 4.02 to 10●●●  ●
SBS™ Mini523520 to 100.25 to 4.02  ●   ●
Powerpole®
PP15 to 45 		554020 to 100.25 to 6.01●●●  ●
SBE® 80 /
SBO® 60 		808016 to 41.3 to 252 ●  8●
Mid Power
SPEC Pak® 		805012 to 62.5 to 13.34,5●●  8 ●
SBS®50 1107516 to 61.3 to 13.32 ●   ●
SBS®75G 1107516 to 61.3 to 13.33●●●  ●
SBS®75X 1107516 to 61.3 to 13.32 ●● 4●
Powerpole® PP75 1207016 to 61.3 to 13.31●●●●
SB®50 1205016 to 61.3 to 13.32 ●●●  ●

Note:

  • Amp ratings are stated per position and based on all positions being fully loaded.
  • Evaluate and test all connectors thoroughly to ensure they are appropriate for the specific applications.
  • UL amp rating:  Consult temperature rise charts for details.
  • CSA amp rating is based on a 30C rise.
  • Quantity of Position equal to "1+" signify that the parts are stackable.
  • Many of the mm² wire sizes are based on calculations. See the catalog for specific mm² wire sizes.
