ZIVAN Battery charger

The majority of battery charger producers manufacture for the specific needs of their own industrial trucks. ZIVAN (a sub company froth the world wide operating ZAPI group) and a specialised producer, develops battery chargers for a range of applications, terms and needs for battery powered vehicles. For every application you will find the right charger here.

For all questions about charging technology ATECH Antriebstechnik is your supplier in all German speaking regions. Our service includes not only sales and repair service but we are also a competent partner in planning charging stations and charging management. Our products are coordinated for all areas and find the best economical solutions for your logistics vehicle pool, no matter what size.

Convince yourself of our competence.

Select your desired product:

Please select the desired filters. Multiple selection possible.

Charger BG15

The recently announced BG15 will replace the proven NGTOP charger.

Note: Due to the topicality we reserve the right to change the product information.

Technical specifications

Power Connection 3-phase
Output Voltage High-Voltage
Level of Performance -
Brand ZIVAN
Application for high-voltage applications

Battery

Lead acid, lead gel, AGM, NiCd, lithium etc.

Type

three-phase

Input voltage

400 VAC

Input current

22 A

Input frequency

50 - 60 Hz

Output voltage

80 V

Output current

160 A

Charging curve

IUa Fastcharge C.B.

Ambient temperature

 -

Efficiency

 -

Protection

 -

Dimensions

700 x 361 x 540 mm

Other

Network switch

Single CANBUS master logic

Input: cable 200cm, 4mm²

Output: cable N-N 300cm, 50mm²
